Danfoss H-series scroll compressors are manufactured using the most advanced machining, assembly, and process contral techniques. In design of both the compressor and the factory, very high standards of reliability and process control were first priority. The result is a highly efficient product with the highest reliability obtainable, and a low sound level. The H-series compressors can be black or bule depending on the production site.
• The widest product range in inverter technology: from 2.5 to 26TR, there is always a Danfoss prequalified compressor and drive available to provide stunning efficiency;
• Excellent energy efficiency across the complete scroll range, offering performance that ranks among the best in the market;
• Low ODP refrigerants with a complete compressor range using R410A;
• Compact solutions for smaller footprints;
• Reduced sound levels, for greater comfort in residential, commercial areas.|
Model |
|
||||||||||||||||||||||||||||||||
| Refrigerant | R410A | ||||||||||||||||||||||||||||||||
|
Voltage |
380-415V,50 Hz ; 460V,60 Hz |
||||||||||||||||||||||||||||||||
| Nominal Cap. 60Hz (TR) | 10 | ||||||||||||||||||||||||||||||||
| 50 Hz, EN12900 ratings | Cooling capacity | W | 26307 | ||||||||||||||||||||||||||||||
| Btu/h | 89759 | ||||||||||||||||||||||||||||||||
| Efficiency | COP in W/W | 3.06 | |||||||||||||||||||||||||||||||
| EER in Btu.h/W | 10.44 | ||||||||||||||||||||||||||||||||
|
50 Hz, ARI ratings |
Cooling capacity |
W |
29610 | ||||||||||||||||||||||||||||||
| Btu/h | 101080 | ||||||||||||||||||||||||||||||||
| Efficiency | COP in W/W | 3.11 | |||||||||||||||||||||||||||||||
| EER in Btu.h/W | 10.6 | ||||||||||||||||||||||||||||||||
|
60 Hz, ARI ratings |
Cooling capacity |
W |
35620 | ||||||||||||||||||||||||||||||
| Btu/h | 121600 | ||||||||||||||||||||||||||||||||
| Efficiency | COP in W/W | 3.2 | |||||||||||||||||||||||||||||||
| EER in Btu.h/W | 10.9 | ||||||||||||||||||||||||||||||||
| Net Weight (kg) | 44 | ||||||||||||||||||||||||||||||||
|
Application |
Residential and light commricial Air conditioning |
||||||||||||||||||||||||||||||||
