-Mitsubishi Compressor is a subsidiary of Mitsubishi Heavy Industries (MHI) and Mitsubishi Electric, the core companies of the Mitsubishi Group in Japan. The two subsidiaries are responsible for the research and development of industrial-grade and commercial/residential compressors, respectively.
-
Core Technology Advantages
1. Energy efficient technology
- Scroll compressor: With e-3D scroll technology as the core, it reduces refrigerant leakage and improves low load efficiency through 3D curved surface design (leading the industry in IPLV value).
- DC inverter technology: Precise control of motor speed, reducing energy consumption and adapting to wide temperature range operation (-25℃ to 55℃).
- Eco-friendly refrigerant compatibility: Supporting low GWP (Global Warming Potential) refrigerants such as R32, CO₂, etc., in line with international environmental standards (e.g. EU F-Gas regulations).
2. High reliability design
- Totally enclosed piston compressor (e.g. CB series): Adopting corrosion-resistant materials and precision machining process, the life span can reach more than 10 years, adapting to extreme working conditions (high temperature, high humidity, salt spray environment).
- Anti-liquid strike capability: Optimised internal structure design to avoid mechanical damage caused by refrigerant liquid reflux.
Main Product Lines
1. Industrial compressors
- CB series piston compressors: Covering 5HP to 15HP, with cooling capacity up to 44,700 Kcal/h, suitable for industrial chiller and cold chain logistics equipment.
- Centrifugal compressors: For large central air-conditioning systems, with a cooling capacity of up to 3,000 RT per unit and an energy efficiency ratio (COP) of over 6.0.
2. Commercial/residential compressors
- e-3D scroll series: Suitable for domestic air-conditioners and multi-connected units (VRF), with noise as low as 52dB(A), supporting intelligent frequency control.
- CO₂ rotor type inverter compressor (KXB series): Designed for environmentally friendly refrigerant, applied to heat pump water heaters and cold chain equipment.
Fields of Application
- Industrial refrigeration: Food freezing, pharmaceutical cold chain, chemical cooling.
- Building air-conditioning: Large commercial complexes, data centres, hospitals.
- Transportation field: Ship air-conditioning, railway vehicle refrigeration system.
- New energy: Heat pump heating, electric vehicle thermal management system (co-operation with Toyota, Honda and other car companies).
Types of Mitsubishi Compressor
Mitsubishi double-rotor compressor
- Working principle: The compressor consists of two rotors, unbalanced mass staggered 180 ° symmetrical arrangement, each other in the opposite direction of the centrifugal force generated to offset each other, reducing vibration. During operation, the rotors are driven to rotate by the motor, so that the refrigerant is compressed in the cylinder to realise the refrigeration cycle.
- Application: Commonly used in domestic air conditioning and some small commercial air conditioning system, suitable for higher noise requirements, the space is relatively small places.
-Common models
1.ZD4016S
Displacement:17cc
The maximum heating capacity:11900 watts
2.Svb 140 14CC
The maximum heating capacity:11,700 watts
Heating low-temperature capacity:8500 watts
APF:7.4.
Mitsubishi scroll compressor
- Working principle: The dynamic scroll disc and static scroll disc engage with each other to form a compression chamber, the motor drives the dynamic scroll disc to do eccentric movement, so that the refrigerant gas is gradually compressed in the compression chamber, the pressure rises, to achieve the function of refrigeration or heating.
- Application: Widely used in domestic and commercial air-conditioning systems and some places with high requirements for cooling effect and stability, such as data centres and hospitals.
-Common models:
AN33/42/47/52YBUMT, AN36/47YKLMT, AN66YOSMT series
Power range:from 1.5HP to 5HP
Operating voltage:220V/380V
Refrigerant:R410A
